Formed Tubular "U" Shaped Heater
Formed Tubular "U" Shaped Heater | .440 DIA, 2" 150 LB. ANSI Flange | 20,000W, 460V-3PH | Cross-Reference
Looking for a formed tubular “U” shaped heater replacement that matches your original spec exactly? This .440 diameter U-shaped tubular heater with 2″ 150 lb. steel ANSI flange, 20,000 watts, 460 volt 3-phase construction is manufactured as a direct OEM replacement.
This formed tubular “U” shaped heater is precision-built for immersion heating applications requiring reliable, high-wattage thermal output. Constructed with (3) Type 316 stainless steel elements formed into a U-shape, mounted on a 2″ 150 lb. steel ANSI flange for secure, code-compliant installation. Featuring a 27″ immersion length and 4″ cold length, this unit is built without a terminal enclosure and does not include a gasket, giving you a drop-in equivalent without redesign or requalification.
Standard Sizes and Ratings
| Spec | Detail |
|---|---|
| Product Type | Formed Tubular “U” Shaped Heater |
| Element Diameter | .440″ |
| Flange | 2″ 150 LB. Steel ANSI Flange |
| Wattage | 20,000W |
| Voltage | 460V – 3PH |
| Element Material | (3) Type 316 Stainless Steel |
| Immersion Length | 27″ |
| Cold Length | 4″ |
| Terminal Enclosure | Not Included |
| Gasket | Not Included |
- Exact cross-reference match — built to original OEM spec for seamless compatibility
- Type 316 stainless steel elements — superior corrosion resistance for immersion service
- 150 LB. ANSI flange mount — secure, standardized installation
- High wattage output — 20,000W at 460V-3PH for demanding process heating
- Custom immersion lengths, flange sizes, and wattages available — need a different configuration? We build to order
